Age regression from EEG (applied case study)#

Estimated reading time:7 minutes

Can a feature-based regression head predict a child’s age from a few seconds of resting-state EEG, on subjects the model has never seen? This applied case study takes the Healthy Brain Network release ds005505 (Alexander et al. 2017, doi:10.1038/sdata.2017.181), surfaced through NEMAR (Delorme et al. 2022, doi:10.1093/nargab/lqac023), wires up an eegdash.EEGDashDataset query, builds a strict subject-aware split (Cisotto and Chicco 2024, doi:10.7717/peerj-cs.2256), fits a sklearn.linear_model.Ridge head on band-power features, and reports Pearson r, Spearman rho, R^2, and MAE against a median-baseline predictor. EEG-based brain-age regression has a long line of prior work (Zoubi et al. 2018, doi:10.3389/fnhum.2018.00461). The headline question here is not whether we beat the published literature; the honest one is, does the model beat the train-set median predictor on never-seen subjects?

# Difficulty: 3-star (advanced applied project)

Learning objectives#

After this case study you will be able to:

Requirements#

Step 1. Setup, seeds, parametrised cache#

import os
import warnings
from pathlib import Path

import matplotlib.pyplot as plt
import numpy as np
import pandas as pd
from scipy.stats import pearsonr, spearmanr
from sklearn.linear_model import Ridge
from sklearn.metrics import mean_absolute_error, r2_score
from sklearn.model_selection import GroupKFold
from sklearn.pipeline import Pipeline
from sklearn.preprocessing import StandardScaler

from eegdash.viz import use_eegdash_style

use_eegdash_style()
warnings.simplefilter("ignore", category=FutureWarning)
warnings.simplefilter("ignore", category=UserWarning)
SEED = 42
np.random.seed(SEED)
rng = np.random.default_rng(SEED)
cache_dir = Path(os.environ.get("EEGDASH_CACHE_DIR", Path.cwd() / "eegdash_cache"))
cache_dir.mkdir(parents=True, exist_ok=True)

Step 2. Predict, what do you expect?#

Predict. Constant predictors set the chance level. A model that always returns the train-set median age scores r2 = 0 against the test-set mean by definition. Brain-age regression on faint resting EEG is a hard inverse problem; what r2 do you expect a Ridge head on ~12 features to reach with only ~12 held-out subjects: 0.10? 0.40? 0.80? Write your guess before scrolling.

Step 4. Build a Ridge regression head on top of features#

A sklearn.preprocessing.StandardScaler then sklearn.linear_model.Ridge sklearn.pipeline.Pipeline (Pedregosa et al. 2011, doi:10.5555/1953048.2078195) is the regression analogue of a logistic head. alpha=1.0 is a defensible default for a 12-feature table, and random_state=42 keeps the loop byte stable.

def make_regressor() -> Pipeline:
    """Return a fresh ``StandardScaler -> Ridge`` Pipeline."""
    return Pipeline(
        [
            ("scaler", StandardScaler()),
            ("clf", Ridge(alpha=1.0, random_state=SEED)),
        ]
    )

Step 5. Cross-subject 5-fold split, no subject leakage#

Run. sklearn.model_selection.GroupKFold keyed on subject is the contract: every subject appears in exactly one test fold. We assert zero subject overlap before scoring, and we pool the held-out predictions across folds so the diagnostic plate in step 7 sees every subject once. Subject leakage routinely produces optimistic accuracies (Cisotto and Chicco 2024 Tip 9), so the assertion below is non-negotiable.

groups = metadata["subject"].to_numpy()
unique_subjects = np.unique(groups)
n_folds = min(5, len(unique_subjects))
splitter = GroupKFold(n_splits=n_folds)

fold_r2: list[float] = []
fold_mae: list[float] = []
fold_baseline_mae: list[float] = []
held_records: list[tuple[str, str, float, float]] = []
for k, (tr, te) in enumerate(splitter.split(X, y, groups=groups)):
    train_subj = set(groups[tr].tolist())
    test_subj = set(groups[te].tolist())
    overlap = train_subj & test_subj
    assert not overlap, f"Fold {k} leaked subjects: {sorted(overlap)}"

    pipe = make_regressor().fit(X[tr], y[tr])
    y_pred = pipe.predict(X[te])
    fold_r2.append(float(r2_score(y[te], y_pred)))
    fold_mae.append(float(mean_absolute_error(y[te], y_pred)))
    median_pred = float(np.median(y[tr]))
    fold_baseline_mae.append(
        float(mean_absolute_error(y[te], np.full_like(y[te], median_pred)))
    )
    for sid, sx, true_val, pred_val in zip(
        metadata.loc[te, "subject"].tolist(),
        metadata.loc[te, "sex"].tolist(),
        y[te].tolist(),
        y_pred.tolist(),
    ):
        held_records.append((sid, sx, float(true_val), float(pred_val)))
    print(
        f"Fold {k}: r2={fold_r2[-1]:+.3f} | mae={fold_mae[-1]:.3f} yr | "
        f"baseline_mae={fold_baseline_mae[-1]:.3f} yr"
    )

mean_r2 = float(np.mean(fold_r2))
std_r2 = float(np.std(fold_r2, ddof=1))
mean_mae = float(np.mean(fold_mae))
mean_baseline_mae = float(np.mean(fold_baseline_mae))

Step 6. A common mistake, and how to recover#

Run. A frequent slip is wiring a non-numeric age column into sklearn.linear_model.Ridge. age arrives as strings if a CSV was loaded without dtype hints (or if a NEMAR sidecar serialises it as text), and Ridge then refuses to fit. We trigger the failure on purpose with try / except so the error message and the recovery sit next to each other in the rendered gallery.

try:
    bad_y = metadata["age"].astype(str).to_numpy()
    Ridge(alpha=1.0, random_state=SEED).fit(X[:8], bad_y[:8])
except (ValueError, TypeError) as exc:
    print(f"Caught {type(exc).__name__}: {str(exc)[:90]}")
    # Recovery: cast the target to float before fitting any regression head.
    fixed_y = pd.to_numeric(metadata["age"], errors="coerce").to_numpy()
    Ridge(alpha=1.0, random_state=SEED).fit(X[:8], fixed_y[:8])
    print(f"Recovery: cast age to float (dtype={fixed_y.dtype}); Ridge fit.")

Step 7. Investigate, three-panel diagnostic plate#

Investigate. A single MAE number hides every failure mode that matters. The sibling _age_regression_figure.py renders three panels: predicted vs true age (one point per held-out subject, with Pearson r, Spearman rho, R^2, and MAE in a corner box, points colored by sex), per-subject signed residuals sorted by |residual| (orange for over-prediction, blue for under-prediction), and a histogram of window-level errors with a Gaussian density overlay so the bias (mean) and the spread (std) read at a glance. This is the kind of diagnostic Pernet et al. 2019 (doi:10.1038/s41597-019-0104-8) recommend before any clinical claim.

held_df = pd.DataFrame(held_records, columns=["subject", "sex", "true", "pred"])
y_true_pooled = held_df["true"].to_numpy()
y_pred_pooled = held_df["pred"].to_numpy()
subject_pooled = held_df["subject"].tolist()
sex_pooled = held_df["sex"].tolist()

from _age_regression_figure import draw_age_regression_figure

fig = draw_age_regression_figure(
    y_true_subj=y_true_pooled,
    y_pred_subj=y_pred_pooled,
    subject_ids=subject_pooled,
    sex_or_fold=sex_pooled,
    plot_id="project_age_regression",
)
plt.show()

# Pull figure-side metrics back into the script namespace so the
# wrap-up print line stays consistent with the corner box.
fig_metrics = fig._eegdash_age_metrics
print(
    f"figure metrics: r={fig_metrics['pearson_r']:+.3f} | "
    f"rho={fig_metrics['spearman_rho']:+.3f} | "
    f"R^2={fig_metrics['r2']:+.3f} | "
    f"MAE={fig_metrics['mae']:.3f} yr | "
    f"n_subjects={fig_metrics['n_subjects']}"
)

Modify, where to take this next (concept only)#

Modify (concept). Two upgrades close most of the gap to a real scientific result. First, scale the cohort: HBN ships several thousand recordings, and reliable brain-age estimates need at least a few hundred subjects per fold. Second, swap Ridge for a deep encoder, braindecode.models.EEGConformer (Song et al. 2023, doi:10.1109/TNSRE.2022.3230250) trained on raw windows, with the same cross-subject contract enforced at the dataset level. We do not run it here (gpu_required + multi-hour fit out of scope), but the subject-aware split contract above is the floor any such system must still satisfy.

Result, model vs median baseline#

Five folds, disjoint subject test sets. mean +/- std against the regression chance level. The median-baseline MAE is the floor the trained model must come in below. The pooled-window vs subject-level numbers split the disagreement: pooled noise vs subject-level rank reversal (Cisotto and Chicco 2024 Tip 7).

pearson_pooled = float(pearsonr(y_true_pooled, y_pred_pooled).statistic)
spearman_pooled = float(spearmanr(y_true_pooled, y_pred_pooled).statistic)
print(
    f"Cross-subject 5-fold age regression: r2={mean_r2:+.3f} +/- {std_r2:.3f} "
    f"| mae={mean_mae:.3f} yr | baseline_mae={mean_baseline_mae:.3f} yr "
    f"| metric: r2"
)
print(
    f"pooled-window r={pearson_pooled:+.3f} | rho={spearman_pooled:+.3f} | "
    f"subject r={fig_metrics['pearson_r']:+.3f} | "
    f"subject rho={fig_metrics['spearman_rho']:+.3f}"
)
print(
    f"chance: predicting the train-median age scores baseline_mae="
    f"{mean_baseline_mae:.3f} yr on test."
)
assert mean_mae < mean_baseline_mae, "Model MAE must be below the median-baseline MAE."

Wrap-up#

We loaded an HBN-shaped feature table with age as a float column, built a 5-fold GroupKFold split keyed on subject, asserted zero subject leakage, fit a sklearn.linear_model.Ridge head per fold, and reported R^2 plus MAE alongside the median-baseline predictor. The three-panel figure is the diagnostic that surfaces what a single MAE hides: a flat predicted-vs-true cloud means the model regresses toward the train-set mean, a one-sided residual bar chart means a single subject drags the error, and a wide Gaussian on the histogram means the per-window spread leaves little room for clinical claims. Age in HBN is a derived metadata column, not a diagnosis; any clinical framing belongs in a follow-up study with much larger N.

Try it yourself#

References#

See References for the centralised bibliography of papers cited above. Add or amend an entry once in docs/source/refs.bib; every tutorial inherits the update.
