Predict p-factor from EEG with a Braindecode model (deep-learning regime)

Estimated reading time:8 minutes

This is the deep-learning case study for the p-factor regression project. The companion script project_pfactor_features.py covers the feature-based regime; this one trains braindecode.models.EEGConformer end-to-end on raw resting-state windows from the Healthy Brain Network release ds005505 (Alexander et al. 2017, doi:10.1038/sdata.2017.181), surfaced through NEMAR (Delorme et al. 2022, doi:10.1093/nargab/lqac023). The p-factor is a transdiagnostic score from the Child Behavior Checklist (Caspi et al. 2014, doi:10.1177/2167702613497473) and the modelling contract is the clinical-cautious one Cisotto and Chicco 2024 (doi:10.7717/peerj-cs.2256) ask for: cross-subject split, baseline alongside score, no diagnostic claim. Three regimes shape the framing, mirroring cousin tutorial plot_73: train from scratch, fine-tune a pretrained Braindecode encoder (Schirrmeister et al. 2017, doi:10.1002/hbm.23730), and read back where the network looks. The deliverable is a 3-panel figure plus printed metrics. So can a small EEGConformer beat the train-mean predictor on held-out subjects?

Learning objectives

After this case study you will be able to:

• load ds005505 with eegdash.EEGDashDataset and surface p_factor.

• build a strict cross-subject split before any windowing happens.

• train braindecode.models.EEGConformer end-to-end with AdamW.

• read a 3-panel figure: curves, predicted-vs-true scatter, saliency.

Requirements

• Estimated time: ~25 s on CPU, ~10 s on GPU (synthetic surrogate).

• Data downloaded: 0 MB on the synthetic path; ~1.5 GB to fetch the real ds005505 windows on the HBN path (cached after first run).

• Prerequisites: /auto_examples/tutorials/10_core_workflow/plot_11_leakage_safe_split, /auto_examples/tutorials/70_transfer_foundation/plot_72_subject_invariant_regression (the feature analogue of this script).

• Concept page: Leakage and evaluation.

Step 1. Setup, seeding (E3.21), parametrised cache (E3.24)

Numpy and torch seeds make the printed metrics and the rendered curves byte-stable across reruns. The cache dir is parametrised through the EEGDASH_CACHE env var so HPC and local runs share one prepared windowed dataset.

import os
import warnings
from pathlib import Path

import matplotlib.pyplot as plt
import numpy as np
import pandas as pd

from eegdash.viz import use_eegdash_style

use_eegdash_style()
warnings.simplefilter("ignore", category=FutureWarning)
warnings.simplefilter("ignore", category=UserWarning)

SEED = 42
np.random.seed(SEED)
rng = np.random.default_rng(SEED)

cache_dir = Path(os.environ.get("EEGDASH_CACHE_DIR", Path.cwd() / "eegdash_cache"))
cache_dir.mkdir(parents=True, exist_ok=True)

import torch
import torch.nn as nn
import torch.nn.functional as F
from braindecode.models import EEGConformer

torch.manual_seed(SEED)

Step 2. The mental model and the production data path

The case study fixes the data pipeline (8 GSN 128 channels, 100 Hz, 2 s windows) and trains EEGConformer end-to-end with n_outputs=1 on a strict cross-subject split. from-scratch (this script) is the no-transfer baseline that fine-tuned regimes (linear-probe, full-finetune; cousin tutorial plot_73) must beat. The p-factor signal in EEG is faint, so the honest question is “does the network beat the train-set mean on never-seen subjects?”

The canonical production call (run on real ds005505) is:

from eegdash import EEGDashDataset
from braindecode.preprocessing import (
    Preprocessor, create_fixed_length_windows, preprocess,
)
ds = EEGDashDataset(dataset="ds005505", cache_dir=cache_dir,
    description_fields=["subject", "session", "run", "task", "p_factor"])
# HydroCel GSN 128 midline: Fz=E11, Cz, Pz=E62, Oz=E75, C3=E36,
# C4=E104, P3=E52, P4=E92.
ch_names = ["E11", "Cz", "E62", "E75", "E36", "E104", "E52", "E92"]
preprocess(ds, [
    Preprocessor("pick_channels", ch_names=ch_names, ordered=True),
    Preprocessor("resample", sfreq=100),
    Preprocessor("filter", l_freq=1, h_freq=30),
])
windows = create_fixed_length_windows(ds,
    window_size_samples=200, window_stride_samples=200,
    drop_last_window=True, preload=False)

Below we synthesise a Challenge-shaped windowed table with the same column layout so the gallery runs offline (E3.24).

Step 3. Synthesise a Challenge-shaped windowed table

18 subjects, 24 windows each, 8 channels, 200 samples per 2 s window at 100 Hz. p_factor lives at subject level (one score per subject, replicated per window). A faint 10 Hz signal hides in Cz and E62 (the central and parietal midline); everything else is i.i.d. Gaussian noise plus a per-subject offset that the cross-subject split must NOT let the network memorise.

N_SUBJECTS, N_WINDOWS = 18, 24
N_CHANS, N_TIMES = 8, 200
SFREQ = 100.0
CH_NAMES = ("E11", "Cz", "E62", "E75", "E36", "E104", "E52", "E92")

subject_p = rng.normal(0.0, 1.0, size=N_SUBJECTS)
t = np.arange(N_TIMES) / SFREQ
X_list, rows = [], []
for s in range(N_SUBJECTS):
    p = float(subject_p[s])
    bias = 0.10 * (s - N_SUBJECTS / 2)
    for w in range(N_WINDOWS):
        base = rng.standard_normal((N_CHANS, N_TIMES)).astype(np.float32)
        # Faint p-factor signal at 10 Hz on Cz (ch 1) and E62 (ch 2).
        carrier = 0.30 * p * np.sin(2 * np.pi * 10.0 * t).astype(np.float32)
        base[1] += carrier
        base[2] += 0.85 * carrier
        # Subject identity offset that a leaky split would memorise.
        base += np.float32(bias)
        X_list.append(base)
        rows.append(
            {
                "subject": f"sub-{s:02d}",
                "sample_id": f"sub-{s:02d}__w{w:03d}",
                "p_factor": p,
            }
        )
X_all = np.stack(X_list)
meta = pd.DataFrame(rows)
y_all = meta["p_factor"].to_numpy(dtype=np.float32)
print(
    f"X_all={X_all.shape} | y_all={y_all.shape} | "
    f"subjects={meta['subject'].nunique()} | "
    f"p_factor mean={y_all.mean():+.3f} std={y_all.std():.3f}"
)
assert pd.api.types.is_float_dtype(meta["p_factor"]), "p_factor must be float"

Step 4. Predict: what r should chance look like?

Predict. A constant predictor that returns the train-set mean has Pearson r exactly zero on the validation cohort. With 14 train subjects and 4 held-out subjects, what r do you expect a small EEGConformer to reach: 0.05? 0.20? 0.50? Write your guess; the scatter panel will overwrite it.

Step 5. Cross-subject split before windowing

The split operates on unique subjects so no subject’s data appears in both train and validation. Subject leakage is the most common failure mode for clinical EEG regression; an honest validation r demands subject-disjoint cohorts (Cisotto and Chicco 2024 Tip 9, doi:10.7717/peerj-cs.2256).

unique_subj = sorted(meta["subject"].unique())
n_val = max(2, int(round(0.20 * len(unique_subj))))
val_subj = set(unique_subj[-n_val:])
train_subj = set(unique_subj[:-n_val])
assert train_subj.isdisjoint(val_subj), "train/val subject overlap"
train_mask = meta["subject"].isin(train_subj).to_numpy()
val_mask = meta["subject"].isin(val_subj).to_numpy()
X_tr, y_tr = X_all[train_mask], y_all[train_mask]
X_va, y_va = X_all[val_mask], y_all[val_mask]
subj_va = meta.loc[val_mask, "subject"].tolist()
n_train_subjects = int(meta.loc[train_mask, "subject"].nunique())
n_val_subjects = int(meta.loc[val_mask, "subject"].nunique())
print(
    f"train: n_windows={X_tr.shape[0]} n_subjects={n_train_subjects} | "
    f"val: n_windows={X_va.shape[0]} n_subjects={n_val_subjects}"
)

Step 6. Configure EEGConformer for regression

braindecode.models.EEGConformer (Song et al. 2023, doi:10.1109/TNSRE.2022.3230250) pairs convolutional embeddings with a transformer encoder. n_outputs=1 makes the final layer a scalar regression head; num_layers=3 keeps a CPU smoke run under a minute.

def build_model() -> "nn.Module":
    """Return a fresh EEGConformer regression head (n_outputs=1)."""
    return EEGConformer(
        n_chans=N_CHANS,
        n_outputs=1,
        n_times=N_TIMES,
        sfreq=SFREQ,
        num_layers=3,
        num_heads=4,
        final_fc_length="auto",
    )


def normalize_batch(x: "torch.Tensor") -> "torch.Tensor":
    """Per-channel z-score within each window (B, C, T)."""
    return (x - x.mean(dim=2, keepdim=True)) / (x.std(dim=2, keepdim=True) + 1e-6)

Step 7. Run: train across seeds, record per-epoch curves

Run. A single-seed training run on a small target is noisy. We fit the model with N_SEEDS=2 seeds and NUM_EPOCHS=4 and record train MSE, val MSE, and val Pearson r per epoch. The figure folds the seeds into a mean +/- SE band.

NUM_EPOCHS = 4
N_SEEDS = 2
BATCH_SIZE = 32
LEARNING_RATE = 1e-3
WEIGHT_DECAY = 1e-3

EPOCH_AXIS = np.arange(1, NUM_EPOCHS + 1)
train_loss_curve = np.full((N_SEEDS, NUM_EPOCHS), np.nan, dtype=float)
val_loss_curve = np.full((N_SEEDS, NUM_EPOCHS), np.nan, dtype=float)
val_r_curve = np.full((N_SEEDS, NUM_EPOCHS), np.nan, dtype=float)
last_model = None
last_val_pred = np.zeros_like(y_va, dtype=float)


def epoch_loop(model, X_tr_t, y_tr_t, X_va_t, y_va_t, *, epochs, lr, batch):
    """:class:`torch.optim.AdamW` epoch loop with per-epoch val metrics."""
    opt = torch.optim.AdamW(model.parameters(), lr=lr, weight_decay=WEIGHT_DECAY)
    train_mse, val_mse, val_r = [], [], []
    for _ in range(epochs):
        model.train()
        idx = torch.randperm(len(X_tr_t))
        running, count = 0.0, 0
        for i in range(0, len(idx), batch):
            sel = idx[i : i + batch]
            opt.zero_grad()
            pred = model(normalize_batch(X_tr_t[sel])).squeeze(-1)
            loss = F.mse_loss(pred, y_tr_t[sel])
            loss.backward()
            opt.step()
            running += float(loss.item()) * len(sel)
            count += len(sel)
        train_mse.append(running / max(count, 1))
        model.eval()
        with torch.no_grad():
            v_pred = model(normalize_batch(X_va_t)).squeeze(-1).cpu().numpy()
        v_true = y_va_t.cpu().numpy()
        val_mse.append(float(np.mean((v_pred - v_true) ** 2)))
        if v_pred.std() > 1e-9 and v_true.std() > 1e-9:
            val_r.append(float(np.corrcoef(v_pred, v_true)[0, 1]))
        else:
            val_r.append(0.0)
    return train_mse, val_mse, val_r, v_pred


device = "cuda" if torch.cuda.is_available() else "cpu"
print(f"Using device: {device}")
X_tr_t = torch.from_numpy(X_tr).float().to(device)
y_tr_t = torch.from_numpy(y_tr).float().to(device)
X_va_t = torch.from_numpy(X_va).float().to(device)
y_va_t = torch.from_numpy(y_va).float().to(device)
for s in range(N_SEEDS):
    torch.manual_seed(SEED + s)
    np.random.seed(SEED + s)
    model = build_model().to(device)
    tr_mse, va_mse, va_r, last_val_pred = epoch_loop(
        model,
        X_tr_t,
        y_tr_t,
        X_va_t,
        y_va_t,
        epochs=NUM_EPOCHS,
        lr=LEARNING_RATE,
        batch=BATCH_SIZE,
    )
    train_loss_curve[s, :], val_loss_curve[s, :], val_r_curve[s, :] = (
        tr_mse,
        va_mse,
        va_r,
    )
    last_model = model
    print(
        f"seed {s}: epoch {NUM_EPOCHS} | train_mse={tr_mse[-1]:.3f} | "
        f"val_mse={va_mse[-1]:.3f} | val_r={va_r[-1]:+.3f}"
    )

Step 8. Investigate: per-subject scatter and saliency

Investigate. Mean MSE hides which subjects the model misses and which channel-time region it reads. The scatter panel aggregates val predictions to one point per held-out subject; the saliency panel averages |grad x| over the highest-confidence test windows, so the heatmap tells you whether the network read the carrier we hid in Cz/E62 or just memorised the per-subject offset (Schirrmeister et al. 2017, doi:10.1002/hbm.23730).

def compute_saliency(model, X_va_t, y_va_t, *, top_frac=0.5):
    """|grad x|, averaged over the top-confidence half of val windows."""
    if model is None:
        return np.zeros((N_CHANS, N_TIMES), dtype=float)
    model.eval()
    X = X_va_t.clone().detach().requires_grad_(True)
    pred = model(normalize_batch(X)).squeeze(-1)
    err = (pred - y_va_t) ** 2
    n_top = max(1, int(round(top_frac * X.shape[0])))
    keep = torch.topk(-err, n_top).indices  # smallest squared error == highest conf
    out = pred[keep].sum()
    out.backward()
    grad = X.grad.detach().abs().cpu().numpy()
    return grad[keep.cpu().numpy()].mean(axis=0)


saliency_map = np.zeros((N_CHANS, N_TIMES), dtype=float)
saliency_map = compute_saliency(last_model, X_va_t, y_va_t, top_frac=0.5)
print(
    f"saliency: peak channel={CH_NAMES[int(saliency_map.mean(axis=1).argmax())]} | "
    f"peak time idx={int(saliency_map.mean(axis=0).argmax())} | max={saliency_map.max():.3e}"
)

Step 9. Result: the 3-panel diagnostic

Drawing helpers live in a sibling _pfactor_deep_figure module so the plumbing stays out of the rendered case study. The subtitle threads live runtime values: train/val subject counts, epochs, and best val r averaged across seeds.

from _pfactor_deep_figure import draw_pfactor_deep_figure

fig = draw_pfactor_deep_figure(
    train_curves={
        "epochs": EPOCH_AXIS,
        "train_loss": train_loss_curve,
        "val_loss": val_loss_curve,
        "val_r": val_r_curve,
    },
    y_true_subj=y_va,
    y_pred_subj=last_val_pred,
    saliency_map=saliency_map,
    channel_names=CH_NAMES,
    subject_ids=subj_va,
    sfreq=SFREQ,
    n_train_subjects=n_train_subjects,
    n_val_subjects=n_val_subjects,
    plot_id="project_pfactor_deep",
)
plt.show()

fig_metrics = fig._eegdash_pfactor_deep_metrics
print(
    f"figure metrics: r={fig_metrics['pearson_r']:+.3f} | "
    f"R^2={fig_metrics['r2']:+.3f} | MAE={fig_metrics['mae']:.3f} | "
    f"best_val_r={fig_metrics['best_val_r']:+.3f} | n_subjects={fig_metrics['n_subjects']}"
)

Step 10. A common mistake, and how to recover

Run. Wiring p_factor into a regression head as strings is a frequent slip when CSV loaders skip dtype hints; the model then refuses to backprop. We trigger it with try/except so the failure mode is visible (Nederbragt et al. 2020, doi:10.1371/journal.pcbi.1008090).

try:
    bad_y = meta["p_factor"].astype(str).to_numpy()
    torch.tensor(bad_y[:BATCH_SIZE], dtype=torch.float32)
except (ValueError, TypeError) as exc:
    print(f"Caught {type(exc).__name__}: {str(exc)[:90]}")
    fixed = pd.to_numeric(meta["p_factor"], errors="coerce").to_numpy()
    fixed_t = torch.from_numpy(fixed[:BATCH_SIZE]).float()
    print(
        f"Recovery: cast p_factor to float (dtype={fixed.dtype}); shape={tuple(fixed_t.shape)}."
    )

Step 11. Modify: from-scratch -> linear-probe -> full-finetune

Modify (concept). This script ran the from-scratch regime; cousin tutorial plot_73 carries the recipe for linear-probe and full-finetune. To extend: pretrain the same EEGConformer on a related task, reload the encoder with strict=False, toggle requires_grad on the head only (linear-probe) or on every parameter (full-finetune), keep the rest constant, and compare best_val_r and gap-vs-from-scratch on the same 3-panel figure.

Wrap-up

We trained a small braindecode.models.EEGConformer end-to-end on a Challenge-shaped windowed table, kept the cross-subject split strict, recorded train/val curves and val r across two seeds, scored the held-out subjects, and pulled a saliency map back through the network. The p-factor signal in EEG is genuinely faint and p_factor is a derived score, not a diagnosis; any clinical framing belongs in a follow-up study with much larger N.

Try it yourself

• Swap braindecode.models.EEGConformer for braindecode.models.ShallowFBCSPNet and rerun.

• Bump N_SEEDS to 5 and report the 5-seed mean r +/- SE.

• Replace the synthetic windows with a real ds005505 query (/auto_examples/tutorials/10_core_workflow/plot_10_preprocess_and_window).

• Pretrain on eyes-open vs eyes-closed and run linear-probe; compare best_val_r with the from-scratch run from this script.

References

See References for the centralised bibliography of papers cited above. Add or amend an entry once in docs/source/refs.bib; every tutorial inherits the update.
