Is resting-state EEG even predictive of the BIDS sex label? (Project Starter)

Estimated reading time:10 minutes

A canonical “is this signal even predictive?” benchmark task on resting-state EEG from OpenNeuro ds005505 (Healthy Brain Network; Alexander et al. 2017), reachable through NEMAR [Delorme et al., 2022]. Log band-power features feed sklearn.pipeline.Pipeline [Pedregosa et al., 2011] with StandardScaler and LogisticRegression. A 3-fold cross-subject loop via GroupKFold keeps every subject in exactly one fold; held-out predictions feed three sklearn display helpers, DecisionBoundaryDisplay, RocCurveDisplay, and ConfusionMatrixDisplay. Do the features separate the classes, how stable is held-out AUC across subjects, and which class does the model confuse?

Learning objectives

• Use eegdash.EEGDashDataset to pull resting-state ds005505 recordings and balance the cohort by the BIDS sex field.

• Compute log band-power features (delta, theta, alpha, beta) per channel from fixed-length 2 s windows.

• Run a 3-fold cross-subject loop with GroupKFold and fit a leakage-safe Pipeline of StandardScaler and LogisticRegression.

• Read the three-panel sklearn-display diagnostic built from DecisionBoundaryDisplay, RocCurveDisplay, and ConfusionMatrixDisplay.

Warning

Treat this as a workflow example, not a result. Three caveats sit on top of every number this script prints. (1) Labels are metadata, not biological ground truth. The BIDS sex field is subject self-report or sponsor-coded; any clean separation speaks to that categorical label, not to chromosomal status, hormones, or brain organisation. (2) Confounds can dominate. Recording site, acquisition system, cap density, age distribution, and within-cohort sampling can all correlate with the label. Cross-site or cross-dataset validation is required before any inference about EEG-vs-sex is supportable (Cisotto and Chicco 2024, Tip 9). (3) A linear baseline is a sanity floor, not a finding. A balanced split on a single dataset with a small subject pool will routinely overstate transferable performance.

Three artefacts answer the project’s central question: do the features separate the classes, how stable is held-out AUC across subjects, and which class does the model confuse?

# Difficulty: 3-star (advanced applied project)

Requirements

• About 3 to 5 minutes on CPU on first run (network pull of six ds005505 .set files); under 30 s once cached.

• Prerequisites: /auto_examples/tutorials/10_core_workflow/plot_11_leakage_safe_split, /auto_examples/tutorials/40_features/plot_42_features_to_sklearn.

• Concept: Features vs. deep learning.

Why a sklearn-display diagnostic?

Three numbers on a line are easy to misread. The same model can post AUC = 0.74 with a balanced confusion matrix or with a 0.95 / 0.05 row-normalised matrix; only the second flags a degenerate classifier that collapsed onto one class. Wiring DecisionBoundaryDisplay, RocCurveDisplay, and ConfusionMatrixDisplay around a leakage-safe cross-subject loop is the canonical sklearn diagnostic for any binary EEG classifier; this project demonstrates it on the sex-prediction question because that is the most direct test of whether the resting- state signal carries predictive information about a categorical label.

Setup. random_state=42 on every estimator and splitter is what keeps the printed metrics byte-stable across runs (E3.21).

import os
import warnings
from pathlib import Path

import matplotlib.pyplot as plt
import mne
import numpy as np
import pandas as pd
from braindecode.datasets import BaseConcatDataset
from braindecode.preprocessing import (
    Preprocessor,
    create_fixed_length_windows,
    preprocess,
)
from sklearn.decomposition import PCA
from sklearn.linear_model import LogisticRegression
from sklearn.metrics import (
    accuracy_score,
    balanced_accuracy_score,
    confusion_matrix,
    roc_auc_score,
)
from sklearn.model_selection import GroupKFold
from sklearn.pipeline import Pipeline
from sklearn.preprocessing import StandardScaler

import eegdash
from eegdash import EEGDashDataset
from eegdash.viz import use_eegdash_style

use_eegdash_style()
mne.set_log_level("ERROR")
warnings.simplefilter("ignore", category=RuntimeWarning)
SEED = 42
rng = np.random.default_rng(SEED)
CACHE_DIR = Path(
    os.environ.get("EEGDASH_CACHE_DIR", Path.home() / ".eegdash_cache")
).resolve()
CACHE_DIR.mkdir(parents=True, exist_ok=True)
print(f"eegdash {eegdash.__version__} | cache_dir={CACHE_DIR}")

Step 1. Pull ds005505 resting-state metadata

Predict. ds005505 carries Healthy Brain Network resting-state recordings on a 128-channel HydroCel cap [Alexander et al., 2017]. The metadata-only first pass populates each record’s description with the BIDS sex field; recordings without a usable label are dropped before any preprocessing fires.

DATASET = "ds005505"
TASK = "RestingState"
N_PER_SEX = 3  # 3 F + 3 M = 6 subjects total; 3-fold leaves 4 train + 2 test
# per fold. Bump to 6 for a tighter ROC band; the project takes
# ~3 min more per extra pair of subjects on first download.
dataset_full = EEGDashDataset(
    cache_dir=CACHE_DIR,
    dataset=DATASET,
    task=TASK,
    description_fields=["subject", "session", "run", "task", "sex", "gender"],
)
candidates = [
    d for d in dataset_full.datasets if d.description.get("sex") in ("F", "M")
]
print(
    f"records with usable sex label: {len(candidates)} / {len(dataset_full.datasets)}"
)

Step 2. Balance the cohort by the BIDS sex label

A 50 / 50 sex balance pins the chance line at 0.50 on every fold. We sort the candidate list by subject id (deterministic across runs) and take the first N_PER_SEX of each label so the cohort is reproducible.

by_sex: dict[str, list] = {"F": [], "M": []}
for d in sorted(candidates, key=lambda r: str(r.description.get("subject"))):
    label = str(d.description.get("sex"))
    if len(by_sex[label]) < N_PER_SEX:
        by_sex[label].append(d)
selected = by_sex["F"] + by_sex["M"]
n_subjects = len(selected)
ds_small = BaseConcatDataset(selected)
cohort_summary = pd.Series(
    {
        "n_subjects": n_subjects,
        "n_F": len(by_sex["F"]),
        "n_M": len(by_sex["M"]),
        "raw n_channels": ds_small.datasets[0].raw.info["nchan"],
        "raw sfreq (Hz)": float(ds_small.datasets[0].raw.info["sfreq"]),
    },
    name="value",
).to_frame()
cohort_summary

Step 3. Pick a small montage, resample, and window

Three preprocessors keep the runtime predictable: pick eight HydroCel electrodes spanning midline, fronto-central, parieto-occipital, and bilateral temporal scalp; resample to 100 Hz; apply a 1 to 45 Hz band-pass. Fixed-length 2 s windows feed the feature stage. The 8-channel pick is a deliberate compression: the question is whether resting-state EEG carries predictive information at all, not whether 128 electrodes carry more than 8.

CH_NAMES = ["E22", "E9", "E33", "E11", "E122", "E29", "E124", "Cz"]
TARGET_SFREQ = 100  # Hz
WINDOW_SECONDS = 2.0
window_size_samples = int(WINDOW_SECONDS * TARGET_SFREQ)
preprocess(
    ds_small,
    [
        Preprocessor("pick_channels", ch_names=CH_NAMES),
        Preprocessor("resample", sfreq=TARGET_SFREQ),
        Preprocessor("filter", l_freq=1, h_freq=45),
    ],
    n_jobs=1,
)
windows_ds = create_fixed_length_windows(
    ds_small,
    start_offset_samples=0,
    stop_offset_samples=None,
    window_size_samples=window_size_samples,
    window_stride_samples=window_size_samples,
    drop_last_window=True,
    preload=True,
)
n_channels = len(CH_NAMES)
# Braindecode 1.0+ may return ``EEGWindowsDataset`` (carries ``.raw``)
# or the older ``WindowsDataset`` (carries ``.windows``); both expose
# the sampling rate through ``.info``.
_first_ds = windows_ds.datasets[0]
_info_holder = getattr(_first_ds, "raw", None) or _first_ds.windows
sfreq = float(_info_holder.info["sfreq"])
print(
    f"n_windows={len(windows_ds)} | n_channels={n_channels} | "
    f"sfreq={sfreq:.0f} Hz | window_size_samples={window_size_samples}"
)

Step 4. Materialize windows + per-window subject id and label

The cross-subject splitter needs a groups array shaped (n_windows,) carrying the subject id, and a y array with the class label (0 = F, 1 = M). Iterating the per-record sub-datasets and reading braindecode.datasets.WindowsDataset.description once per record is the most direct route.

SEX_TO_INT = {"F": 0, "M": 1}
CLASS_NAMES = ("F", "M")
X_list: list[np.ndarray] = []
y_list: list[int] = []
groups_list: list[str] = []
for sub_ds in windows_ds.datasets:
    subj = str(sub_ds.description.get("subject"))
    label = SEX_TO_INT[str(sub_ds.description.get("sex"))]
    for k in range(len(sub_ds)):
        x_k, _, _ = sub_ds[k]
        X_list.append(np.asarray(x_k, dtype=np.float32))
        y_list.append(label)
        groups_list.append(subj)
X_raw = np.stack(X_list)
y = np.asarray(y_list, dtype=int)
groups = np.asarray(groups_list)
print(
    f"X_raw.shape={X_raw.shape} | n_F windows={int((y == 0).sum())} | "
    f"n_M windows={int((y == 1).sum())}"
)

Step 5. Compute log band-power features

Per window: one log-power value per channel per band, on delta (1 to 4 Hz), theta (4 to 8 Hz), alpha (8 to 13 Hz), beta (13 to 30 Hz). The feature shape is (n_windows, n_bands * n_channels). log(mean(|FFT|**2)) is the cheapest band-power feature that survives a review [Schirrmeister et al., 2017].

BANDS: tuple[tuple[float, float], ...] = (
    (1.0, 4.0),  # delta
    (4.0, 8.0),  # theta
    (8.0, 13.0),  # alpha
    (13.0, 30.0),  # beta
)
BAND_NAMES = ("delta", "theta", "alpha", "beta")


def log_band_power(
    X_t: np.ndarray, sfreq: float, bands: tuple[tuple[float, float], ...]
) -> np.ndarray:
    """Stack ``log(mean(|FFT|**2))`` per channel per band.

    ``X_t`` is ``(n_windows, n_channels, n_times)``; the return is
    ``(n_windows, len(bands) * n_channels)``.
    """
    spec = np.fft.rfft(X_t, axis=-1)
    power = (np.abs(spec) ** 2) / X_t.shape[-1]
    freqs = np.fft.rfftfreq(X_t.shape[-1], d=1.0 / sfreq)
    feats = []
    for fmin, fmax in bands:
        band_mask = (freqs >= fmin) & (freqs < fmax)
        # Add a tiny floor so log(0) does not appear when a band is empty.
        feats.append(np.log(power[..., band_mask].mean(axis=-1) + 1e-12))
    return np.concatenate(feats, axis=-1).astype(np.float32)


X_features = log_band_power(X_raw, sfreq, BANDS)
n_features = X_features.shape[1]
print(
    f"feature matrix={X_features.shape} (log-power per channel for "
    f"{', '.join(BAND_NAMES)})"
)

Discovery: feature distributions

A quick descriptive table on the first eight features flags dead channels (variance close to zero) and saturated bands (variance much larger than its peers).

feature_names = [f"{b}_{c}" for b in BAND_NAMES for c in CH_NAMES]
features_df = pd.DataFrame(X_features, columns=feature_names)
features_df.iloc[:, :8].describe().round(3)

Step 6. 3-fold cross-subject CV with GroupKFold

Predict. With GroupKFold(n_splits=3) and a 6-subject cohort, every fold trains on 4 subjects and tests on 2. Run. Per fold we store accuracy, AUC, and the held-out predictions; the pooled scores feed the confusion matrix and the pooled ROC.

N_FOLDS = 3
splitter = GroupKFold(n_splits=N_FOLDS)
fold_accuracies: list[float] = []
fold_aucs: list[float] = []
fold_held_out: list[list[str]] = []
fold_assignment = np.full(len(y), -1, dtype=int)
pooled_y_true: list[np.ndarray] = []
pooled_y_pred: list[np.ndarray] = []
pooled_y_score: list[np.ndarray] = []

for fold_idx, (train_idx, test_idx) in enumerate(
    splitter.split(X_features, y, groups=groups)
):
    held_out = sorted(set(groups[test_idx].tolist()))
    fold_held_out.append(held_out)
    fold_assignment[test_idx] = fold_idx

    # Standardize then fit. Per-fold scaling fitted on the train slice
    # only keeps the test fold leakage-safe; logistic regression on
    # untransformed log-power features fails to converge.
    clf = Pipeline(
        steps=[
            ("scaler", StandardScaler()),
            ("logreg", LogisticRegression(random_state=SEED, max_iter=2000)),
        ]
    )
    clf.fit(X_features[train_idx], y[train_idx])
    y_pred_fold = clf.predict(X_features[test_idx])
    y_score_fold = clf.predict_proba(X_features[test_idx])[:, 1]
    fold_accuracies.append(float(accuracy_score(y[test_idx], y_pred_fold)))
    fold_aucs.append(float(roc_auc_score(y[test_idx], y_score_fold)))
    pooled_y_true.append(np.asarray(y[test_idx]))
    pooled_y_pred.append(np.asarray(y_pred_fold))
    pooled_y_score.append(np.asarray(y_score_fold))

y_true_pooled = np.concatenate(pooled_y_true)
y_pred_pooled = np.concatenate(pooled_y_pred)
y_score_pooled = np.concatenate(pooled_y_score)
mean_auc = float(np.mean(fold_aucs))
std_auc = float(np.std(fold_aucs, ddof=0))
pooled_balanced_acc = float(balanced_accuracy_score(y_true_pooled, y_pred_pooled))
pooled_auc = float(roc_auc_score(y_true_pooled, y_score_pooled))
print(
    f"cross-subject CV: AUC={mean_auc:.3f} +/- {std_auc:.3f} | "
    f"balanced_acc={pooled_balanced_acc:.3f} | folds={N_FOLDS}"
)

Result table: per-fold metrics

Chance is 0.50 for both AUC and accuracy on this balanced cohort.

results_df = pd.DataFrame(
    {
        "fold": np.arange(1, N_FOLDS + 1),
        "held-out subjects": [", ".join(s) for s in fold_held_out],
        "accuracy": np.round(fold_accuracies, 3),
        "auc": np.round(fold_aucs, 3),
    }
).set_index("fold")
results_df

Investigate. On a 6-subject balanced cohort with these 32 log- power features, the pooled AUC routinely lands well below 0.50: the small subject pool means a confound (cap fit, age, recording session) locks the model onto the wrong direction on every held-out fold. That is the central caveat of this project: a number this far below chance is not noise, it is a confound-driven failure that an even-larger cohort or a different feature set would have to rescue. Anything above AUC = 0.95 in the same script is a leakage smell: re-check that groups is the subject id and that the cohort balancing step did not collapse the label.

Common mistake: scaling on the union of train and test

Run. A subtle slip when wiring a cross-validation loop is fitting StandardScaler on the full feature matrix before splitting. The mean and std then leak test-fold statistics into the train slice. We trigger the slip on purpose and recover.

try:
    sneaky_train_idx, sneaky_test_idx = next(
        splitter.split(X_features, y, groups=groups)
    )
    # Wrong on purpose: scaler fitted on the union, then split.
    leaky_scaler = StandardScaler().fit(X_features)
    X_leaky = leaky_scaler.transform(X_features)
    leaky_clf = LogisticRegression(random_state=SEED, max_iter=2000).fit(
        X_leaky[sneaky_train_idx], y[sneaky_train_idx]
    )
    leaky_auc = float(
        roc_auc_score(
            y[sneaky_test_idx],
            leaky_clf.predict_proba(X_leaky[sneaky_test_idx])[:, 1],
        )
    )
    # Recovery: rebuild the Pipeline so scaling fits on the train slice
    # only.
    safe_clf = Pipeline(
        [
            ("scaler", StandardScaler()),
            ("logreg", LogisticRegression(random_state=SEED, max_iter=2000)),
        ]
    ).fit(X_features[sneaky_train_idx], y[sneaky_train_idx])
    safe_auc = float(
        roc_auc_score(
            y[sneaky_test_idx],
            safe_clf.predict_proba(X_features[sneaky_test_idx])[:, 1],
        )
    )
    print(
        f"Leaky-scaler AUC={leaky_auc:.3f} | Pipeline AUC={safe_auc:.3f} "
        f"| gap={leaky_auc - safe_auc:+.3f}"
    )
except ValueError as exc:
    print(f"Caught ValueError: {str(exc)[:120]}")

Discovery: the pooled confusion matrix in raw counts

The figure below renders a row-normalised matrix; the table here carries the raw counts so a 0.55 cell can be traced back to 11/20 vs 550/1000.

cm = confusion_matrix(y_true_pooled, y_pred_pooled)
cm_df = pd.DataFrame(
    cm,
    index=[f"true_{c}" for c in CLASS_NAMES],
    columns=[f"pred_{c}" for c in CLASS_NAMES],
)
cm_df

Three-panel sklearn-display diagnostic

The PCA scatter carries the DecisionBoundaryDisplay contour, the ROC panel shows per-fold curves in muted shades plus the pooled curve in dark ink, and the confusion matrix shows whether the diagonal is balanced. The rendering plumbing lives in a sibling _sex_classification_figure module so the project keeps a single call to plug live runtime values into the figure.

PCA + a logistic regression refit in PCA space so the decision contour shares coordinates with the scattered points; the actual model the project reports lives in the original feature space.

X_std = StandardScaler().fit_transform(X_features)
X_pca = PCA(n_components=2, random_state=SEED).fit_transform(X_std)
boundary_clf = LogisticRegression(max_iter=400).fit(X_pca, y)
n_test_subjects = max(1, n_subjects // N_FOLDS)
n_train_subjects = n_subjects - n_test_subjects

from _sex_classification_figure import draw_sex_classification_figure

fig = draw_sex_classification_figure(
    X_pca=X_pca,
    y_classes=y,
    fold_assignment=fold_assignment,
    estimator=boundary_clf,
    fold_aucs=fold_aucs,
    y_true_pooled=y_true_pooled,
    y_pred_pooled=y_pred_pooled,
    y_score_pooled=y_score_pooled,
    class_names=CLASS_NAMES,
    plot_id="project_sex_classification",
    n_train_subjects=n_train_subjects,
    n_test_subjects=n_test_subjects,
    n_features=n_features,
)
plt.show()

Investigate. Read the panels in order. (1) PCA + decision boundary: do F and M markers form even partly separable clouds? Linear separability on log-power features is rare on a 6-subject cohort; partial overlap with a clean contour is the expected picture. (2) ROC curves: is every per-fold curve above the diagonal chance line, or is one held-out fold pulling the pooled AUC down? Big across-fold variance is the honest signature of cross-subject EEG. (3) Confusion matrix: a balanced diagonal in deep blue is the win condition; an off-diagonal stripe means the model has collapsed onto one class. The monospace balanced_acc=... annotation carries the headline metric so the figure stands alone.

Modify

Your turn. Drop the alpha band from BANDS and rerun Step 5 and Step 6. An AUC drop of more than 0.05 means the alpha band carried most of the class-related variance; a smaller drop means the contrast is spread across the spectrum.

Make

Mini-project. Replace LogisticRegression with RandomForestClassifier (default hyperparameters, random_state=42) and rerun Step 6. If the random forest does not beat the linear baseline, that is the most useful finding the project will produce: linear features deserve a linear model.

Wrap-up

Six ds005505 RestingState recordings were balanced by BIDS sex, fed through 4-band log-power features on 8 channels, and scored with a leakage-safe LogisticRegression Pipeline across 3 cross-subject folds. The pooled AUC is the only number worth quoting in a benchmark submission; the per-fold table shows whether that AUC is stable. A clean shape and a chance-anchored AUC only confirm plumbing; signal quality and the sex-vs-confound question are still open [Cisotto and Chicco, 2024].

Try it yourself

• Bump N_PER_SEX from 3 to 6 (12 subjects total) and rerun. The per-fold AUC band should tighten as the cohort grows.

• Replace GroupKFold with LeaveOneGroupOut. With 6 subjects the leave-one-out loop returns 6 folds and a tighter ROC band.

• Append age (description['age']) as a regression target instead of sex, and rerun the same three-panel figure with Ridge plus a continuous-target variant of the diagnostic.

References

See References for the centralised bibliography of papers cited above. Add or amend an entry once in docs/source/refs.bib; every tutorial inherits the update.
