Train a baseline on real SSVEP trials

Estimated reading time:4 minutes

Fit a spectral decoder on subjects 1 and 2 and evaluate subject 3.

These real Nakanishi2015 SSVEP recordings are distributed as the processed nm000118 release (study). Filtering, downsampling and latency handling were already applied; do not shift the event onsets again. CPU is sufficient. Internet is needed for the first download; EEGDASH_CACHE_DIR keeps downloads across runs.

The explicit subset uses 3 participant(s), about 21.1 MB of signal files.

Before you start

Install EEGDash and its dependencies, including scikit-learn. Tutorials 02 and 11 explain windows and subject-disjoint splits. This script repeats the data preparation so it runs independently and returns actual predictions for subject 3 from a model fitted to subjects 1 and 2.

import os
from pathlib import Path

import matplotlib.pyplot as plt
import numpy as np
import pandas as pd
from braindecode.preprocessing import create_windows_from_events

from eegdash import EEGDashDataset
from functools import partial
from eegdash.features import (
    FeatureExtractor,
    extract_features,
    spectral_bands_power,
    spectral_preprocessor,
)
from sklearn.linear_model import LogisticRegression
from sklearn.metrics import ConfusionMatrixDisplay, balanced_accuracy_score
from sklearn.pipeline import make_pipeline
from sklearn.preprocessing import StandardScaler

1. Load and inspect the selected recordings

The classification question is which of twelve flicker frequencies a trial was labelled with. Annotation names are converted to integer targets in numerical frequency order, and the same mapping is checked across subjects. This baseline keeps the source reference and source preprocessing; it does not load the optional average-referenced output from tutorial 10.

cache_dir = Path(os.environ.get("EEGDASH_CACHE_DIR", ".eegdash_cache"))
subjects = ["1", "2", "3"]
dataset = EEGDashDataset(
    cache_dir=cache_dir,
    dataset="nm000118",
    subject=subjects,
    session="0",
    run="0",
    task="ssvep",
    n_jobs=1,
)
assert len(dataset.datasets) == len(subjects)
print(dataset.description[["subject", "session", "run"]])
raw = dataset.datasets[0].raw
sfreq = raw.info["sfreq"]
channel_names = raw.ch_names
class_names = sorted(set(raw.annotations.description), key=float)
mapping = {name: index for index, name in enumerate(class_names)}
assert len(mapping) == 12
for recording in dataset.datasets:
    assert recording.raw.ch_names == channel_names
    assert recording.raw.info["sfreq"] == sfreq
    assert set(recording.raw.annotations.description) == set(mapping)
print(f"Channels: {channel_names}; sampling rate: {sfreq} Hz")
print("Observed stimulus frequencies (Hz):", class_names)

  subject session run
0       1       0   0
1       2       0   0
2       3       0   0
Channels: ['PO7', 'PO3', 'POz', 'PO4', 'PO8', 'O1', 'Oz', 'O2']; sampling rate: 256.0 Hz
Observed stimulus frequencies (Hz): ['9.25', '9.75', '10.25', '10.75', '11.25', '11.75', '12.25', '12.75', '13.25', '13.75', '14.25', '14.75']

2. Window the observed trials

Each four-second trial is an (8, 1024) voltage array. EEGDash will read these windows in batches, preserving row alignment with the metadata and target vector. The class-count table confirms what each subject contributes before a training split is applied. The source event lasts 4.15 seconds; its final 0.15 seconds are unused.

window_size = int(4 * sfreq)
windows = create_windows_from_events(
    dataset,
    mapping=mapping,
    window_size_samples=window_size,
    window_stride_samples=window_size,
    on_last_window="drop",
    preload=True,
)
metadata = windows.get_metadata().reset_index(drop=True)
y = metadata["target"].to_numpy(dtype=int)
assert len(windows) == len(metadata)
assert set(y) == set(mapping.values())
assert not metadata.duplicated(["subject", "session", "run", "i_start_in_trial"]).any()
print(pd.crosstab(metadata["subject"], y))

print(
    "Windows:",
    len(windows),
    "with",
    len(channel_names),
    "channels and",
    window_size,
    "samples",
)

col_0    0   1   2   3   4   5   6   7   8   9   10  11
subject
1        15  15  15  15  15  15  15  15  15  15  15  15
2        15  15  15  15  15  15  15  15  15  15  15  15
3        15  15  15  15  15  15  15  15  15  15  15  15
Windows: 540 with 8 channels and 1024 samples

3. Summarize stimulus-band power without learning from other trials

EEGDash’s spectral preprocessor computes Welch power on each real window. A four-second segment gives a 0.25 Hz grid. The narrow bands below each contain the grid point at one of the twelve observed stimulus frequencies; their half-bin margins exclude neighbouring bins. The same definition is used for every trial, regardless of its label.

FeatureExtractor shares the spectrum across all band/channel outputs. Twelve frequency bands times eight channels give 96 named columns. The power function sums PSD values in each band; keep the resolution fixed when comparing their scale. Log compression and a positive numerical floor act per value, without learning anything from other trials. The scaler below still needs to be fitted only on training participants.

stimulus_bands = {
    name: (float(name) - 0.125, float(name) + 0.125) for name in class_names
}
spectral = FeatureExtractor(
    {"power": partial(spectral_bands_power, bands=stimulus_bands)},
    preprocessor=partial(
        spectral_preprocessor,
        fs=sfreq,
        nperseg=window_size,
        noverlap=0,
        f_min=8,
        f_max=16,
    ),
)
feature_table = extract_features(
    windows, spectral, batch_size=64, n_jobs=1
).to_dataframe()
features = np.log(np.maximum(feature_table.to_numpy(), 1e-30))
assert features.shape == (len(metadata), len(mapping) * len(channel_names))
assert np.isfinite(features).all()
print("EEGDash spectral features:", features.shape)

Extracting features:   0%|          | 0/3 [00:00<?, ?it/s]
Extracting features: 100%|██████████| 3/3 [00:00<00:00, 23.23it/s]
Extracting features: 100%|██████████| 3/3 [00:00<00:00, 23.18it/s]
EEGDash spectral features: (540, 96)

4. Fit all learned transformations on training participants

The Boolean masks select complete participants. StandardScaler learns a mean and scale for each frequency feature from training rows only, then applies them to subject 3. Logistic regression learns twelve-class decision weights on those scaled features. max_iter=1000 is an optimization limit, not a number of EEG training trials and not a promise of convergence.

Balanced accuracy averages recall over the twelve classes. The displayed 1/12 is the expected value for uniform random guessing, not a simulated score. Rows of the normalized confusion matrix correspond to true frequencies; columns show predicted frequencies. Concentration near the diagonal indicates correct decisions; an off-diagonal pattern shows which frequencies are confused. The code accepts a low measured score as a valid outcome.

groups = metadata["subject"].astype(str).to_numpy()
train, test = groups != "3", groups == "3"
assert set(groups[train]).isdisjoint(groups[test])
assert set(y[train]) == set(y[test]) == set(mapping.values())
model = make_pipeline(StandardScaler(), LogisticRegression(max_iter=1000))
model.fit(features[train], y[train])
predictions = model.predict(features[test])
score = balanced_accuracy_score(y[test], predictions)
print(f"Held-out subject 3 balanced accuracy: {score:.3f}; chance: {1 / 12:.3f}")
ConfusionMatrixDisplay.from_predictions(
    y[test],
    predictions,
    display_labels=class_names,
    normalize="true",
    include_values=False,
    xticks_rotation=90,
)
plt.title("Subject 3: observed frequency (Hz)")
plt.show()

Held-out subject 3 balanced accuracy: 0.256; chance: 0.083

Extend the experiment without reusing the test set

A single subject can be unusually easy or difficult. Tutorial 51 evaluates all three subjects once with LOSO to expose that variation. Before trying a neural decoder or altering the spectral band, choose a validation protocol inside the training cohort; repeated inspection of subject 3 would turn it into development data.
