Preprocess and window recorded EEG#
Select EEG channels, apply an explicit reference, and save reusable windows.
These real Nakanishi2015 SSVEP recordings are distributed as the processed
nm000118 release
(study).
Filtering, downsampling and latency handling were already applied; do not
shift the event onsets again. CPU is sufficient. Internet is needed for the
first download; EEGDASH_CACHE_DIR keeps downloads across runs.
The explicit subset uses 1 participant(s), about 7.0 MB of signal files.
Before you start#
Install EEGDash with its EEGPrep tutorial dependencies; tutorials 01 and 02 introduce Raw and window indexing. This file independently loads the recording and writes an average-referenced prepared dataset. Allow additional disk space for that output as well as the original download.
import os
from pathlib import Path
import matplotlib.pyplot as plt
import numpy as np
import pandas as pd
from braindecode.preprocessing import create_windows_from_events
from eegdash import EEGDashDataset
from braindecode.preprocessing import (
Preprocessor,
RemoveDCOffset,
RemoveCommonAverageReference,
preprocess,
)
1. Load and inspect the selected recordings#
Check the source rate, channel names and stimulus-frequency descriptions before applying transforms. This is already a processed SSVEP release, so a generic filtering recipe intended for unprocessed acquisition would not be an appropriate default. The following DC-offset and reference operations are explicit changes to the source representation, separate from its existing filtering.
cache_dir = Path(os.environ.get("EEGDASH_CACHE_DIR", ".eegdash_cache"))
subjects = ["1"]
dataset = EEGDashDataset(
cache_dir=cache_dir,
dataset="nm000118",
subject=subjects,
session="0",
run="0",
task="ssvep",
n_jobs=1,
)
assert len(dataset.datasets) == len(subjects)
print(dataset.description[["subject", "session", "run"]])
raw = dataset.datasets[0].raw
sfreq = raw.info["sfreq"]
channel_names = raw.ch_names
class_names = sorted(set(raw.annotations.description), key=float)
mapping = {name: index for index, name in enumerate(class_names)}
assert len(mapping) == 12
for recording in dataset.datasets:
assert recording.raw.ch_names == channel_names
assert recording.raw.info["sfreq"] == sfreq
assert set(recording.raw.annotations.description) == set(mapping)
print(f"Channels: {channel_names}; sampling rate: {sfreq} Hz")
print("Observed stimulus frequencies (Hz):", class_names)
subject session run
0 1 0 0
Channels: ['PO7', 'PO3', 'POz', 'PO4', 'PO8', 'O1', 'Oz', 'O2']; sampling rate: 256.0 Hz
Observed stimulus frequencies (Hz): ['9.25', '9.75', '10.25', '10.75', '11.25', '11.75', '12.25', '12.75', '13.25', '13.75', '14.25', '14.75']
Apply EEGPrep offset and reference components#
preprocess runs the list in order. After selecting EEG channels, the
Braindecode EEGPrep adapters convert to EEGPrep’s representation and back.
RemoveDCOffset subtracts each channel’s temporal median, while
RemoveCommonAverageReference subtracts the instantaneous channel mean.
These are different axes: the first centers each channel over the recording;
the second references each time sample across the selected EEG channels.
Neither operation is a claim that this already-processed source needs a
full artifact-cleaning pipeline. No ASR, channel rejection or extra filter
is applied. The median uses the complete recording, so this preparation is
appropriate for an offline demonstration, not causal online prediction.
This cap contains eight posterior channels, so its average is the mean of those eight sensors, not a whole-head reference. The operation can change common SSVEP components as well as unwanted common signals. It illustrates a reproducible preprocessing decision, not a claim that this reference always improves decoding.
Preserve the source montage and avoid filtering already filtered trials. Average reference needs voltage channels, not electrode coordinates.
annotations_before = raw.annotations.copy()
measurement_date = raw.info["meas_date"]
n_samples_before = raw.n_times
preprocess(
dataset,
[
Preprocessor("pick", picks="eeg"),
RemoveDCOffset(),
RemoveCommonAverageReference(),
],
)
channel_names = dataset.datasets[0].raw.ch_names
# These two components do not resample or cut data. The format conversion
# can quantize annotation latencies, so preserve original event timing once
# the sample-grid invariants have been verified. Restore the measurement date
# first because annotations may use it as their absolute time origin.
assert raw.n_times == n_samples_before and raw.info["sfreq"] == sfreq
raw.set_meas_date(measurement_date)
raw.set_annotations(annotations_before)
assert raw.annotations.orig_time == annotations_before.orig_time
np.testing.assert_array_equal(
raw.annotations.description, annotations_before.description
)
np.testing.assert_array_equal(raw.annotations.onset, annotations_before.onset)
np.testing.assert_array_equal(raw.annotations.duration, annotations_before.duration)
/home/runner/work/EEGDash/EEGDash/.venv/lib/python3.12/site-packages/braindecode/preprocessing/preprocess.py:78: UserWarning: apply_on_array can only be True if fn is a callable function. Automatically correcting to apply_on_array=False.
warn(
Reading 0 ... 218519 = 0.000 ... 853.590 secs...
/tmp/tmp1tl3_smx.set
Field 'subject' is missing from the EEG dictionnary, adding it.
Field 'group' is missing from the EEG dictionnary, adding it.
Field 'condition' is missing from the EEG dictionnary, adding it.
Field 'session' is missing from the EEG dictionnary, adding it.
Field 'comments' is missing from the EEG dictionnary, adding it.
Field 'times' is missing from the EEG dictionnary, adding it.
Field 'icaact' is missing from the EEG dictionnary, adding it.
Field 'icachansind' is missing from the EEG dictionnary, adding it.
Field 'urchanlocs' is missing from the EEG dictionnary, adding it.
Field 'urevent' is missing from the EEG dictionnary, adding it.
Field 'eventdescription' is missing from the EEG dictionnary, adding it.
Field 'epoch' is missing from the EEG dictionnary, adding it.
Field 'epochdescription' is missing from the EEG dictionnary, adding it.
Field 'stats' is missing from the EEG dictionnary, adding it.
Field 'specdata' is missing from the EEG dictionnary, adding it.
Field 'specicaact' is missing from the EEG dictionnary, adding it.
Field 'splinefile' is missing from the EEG dictionnary, adding it.
Field 'icasplinefile' is missing from the EEG dictionnary, adding it.
Field 'dipfit' is missing from the EEG dictionnary, adding it.
Field 'history' is missing from the EEG dictionnary, adding it.
Field 'saved' is missing from the EEG dictionnary, adding it.
Field 'etc' is missing from the EEG dictionnary, adding it.
Field 'datfile' is missing from the EEG dictionnary, adding it.
Field 'run' is missing from the EEG dictionnary, adding it.
Field 'roi' is missing from the EEG dictionnary, adding it.
/tmp/tmpazfpw9iy.set
Field 'subject' is missing from the EEG dictionnary, adding it.
Field 'group' is missing from the EEG dictionnary, adding it.
Field 'condition' is missing from the EEG dictionnary, adding it.
Field 'session' is missing from the EEG dictionnary, adding it.
Field 'comments' is missing from the EEG dictionnary, adding it.
Field 'times' is missing from the EEG dictionnary, adding it.
Field 'icaact' is missing from the EEG dictionnary, adding it.
Field 'icachansind' is missing from the EEG dictionnary, adding it.
Field 'urchanlocs' is missing from the EEG dictionnary, adding it.
Field 'urevent' is missing from the EEG dictionnary, adding it.
Field 'eventdescription' is missing from the EEG dictionnary, adding it.
Field 'epoch' is missing from the EEG dictionnary, adding it.
Field 'epochdescription' is missing from the EEG dictionnary, adding it.
Field 'stats' is missing from the EEG dictionnary, adding it.
Field 'specdata' is missing from the EEG dictionnary, adding it.
Field 'specicaact' is missing from the EEG dictionnary, adding it.
Field 'splinefile' is missing from the EEG dictionnary, adding it.
Field 'icasplinefile' is missing from the EEG dictionnary, adding it.
Field 'dipfit' is missing from the EEG dictionnary, adding it.
Field 'history' is missing from the EEG dictionnary, adding it.
Field 'saved' is missing from the EEG dictionnary, adding it.
Field 'etc' is missing from the EEG dictionnary, adding it.
Field 'datfile' is missing from the EEG dictionnary, adding it.
Field 'run' is missing from the EEG dictionnary, adding it.
Field 'roi' is missing from the EEG dictionnary, adding it.
2. Window the observed trials#
Size and stride are equal to 1,024 samples, giving a four-second input tensor
at 256 Hz. The last incomplete portion of each event is discarded instead of
creating overlapping examples. Each row in metadata must correspond to
one item in windows; labels remain the observed frequency classes.
After stacking, X has axes (trials, channels, samples) and still uses
volts. The channel-mean check verifies the reference operation at each time
sample. It says nothing about classifier performance or artifact removal.
The source event lasts 4.15 seconds; its final 0.15 seconds are unused.
window_size = int(4 * sfreq)
windows = create_windows_from_events(
dataset,
mapping=mapping,
window_size_samples=window_size,
window_stride_samples=window_size,
on_last_window="drop",
preload=True,
)
metadata = windows.get_metadata().reset_index(drop=True)
y = metadata["target"].to_numpy(dtype=int)
assert len(windows) == len(metadata)
assert set(y) == set(mapping.values())
assert not metadata.duplicated(["subject", "session", "run", "i_start_in_trial"]).any()
print(pd.crosstab(metadata["subject"], y))
X = np.stack([window[0] for window in windows])
assert X.shape == (len(metadata), len(channel_names), window_size)
assert np.isfinite(X).all()
print("Windows:", X.shape)
assert np.allclose(X.mean(axis=1), 0, atol=1e-10)
col_0 0 1 2 3 4 5 6 7 8 9 10 11
subject
1 15 15 15 15 15 15 15 15 15 15 15 15
Windows: (180, 8, 1024)
3. Save the prepared data in the persistent cache#
Braindecode saves signal data together with the information needed to index windows and recover their descriptions. Keep the whole output directory, not just a FIF file. The directory name distinguishes this average-referenced version from the source-reference windows in tutorial 13.
The plotted channels should be read in the context of that reference: their
instantaneous average is zero, but each waveform need not have zero temporal
mean. Tutorial 13 demonstrates reloading and checking prepared datasets;
pass this page’s printed directory to load_concat_dataset to inspect this
specific reference choice in a later session.
This tutorial owns this named output. Re-running refreshes that output.
prepared_path = cache_dir / "tutorial_10_nm000118_average_reference"
prepared_path.mkdir(parents=True, exist_ok=True)
windows.save(str(prepared_path), overwrite=True)
print("Saved reusable windows:", prepared_path.resolve())
fig, ax = plt.subplots(figsize=(8, 3), layout="constrained")
ax.plot(np.arange(window_size) / sfreq, X[0].T * 1e6)
ax.set(xlabel="Time (s)", ylabel="Voltage (µV)", title="Average-referenced trial")
plt.show()
Writing /home/runner/eegdash_cache/tutorial_10_nm000118_average_reference/0/0-raw.fif
Closing /home/runner/eegdash_cache/tutorial_10_nm000118_average_reference/0/0-raw.fif
[done]
Saved reusable windows: /home/runner/eegdash_cache/tutorial_10_nm000118_average_reference
